InHand Functionally Capable VT310 Vehicle Tracking Gateway

The VT310 is a high precision, functionally capable vehicle tracking gateway with multiple interfaces.Equipped with the cloud-based remote fleet management platform, it offers remote vehicle management to save costs and improve the efficiency of a fleet.

Multiple Interface for Multiple Network Options

Real-Time Vehicle Monitoring

Uninterrupted High-precision Vehicle Positioning

InHand Fleet Management Cloud Platform

Power-Saving and Long-Lasting Battery

Who is This For?

With extensive built-in interfaces, multiple diagnostic protocols, and low power consumption, fleet managers can rely on the T310 to track and manage public transportation vehicles, rental cars, semi-trucks, and heavy equipment with accuracy and efficiency via any third-party telematics platform.

InHand, Global Leader of Industrial IoT

The VT310 Tracking Gateway is a state-of-the-art, high-performing telematics gateway for fleet management and vehicle tracking. With extensive built-in interfaces and multiple diagnostic protocols, fleet managers can rely on the VT310 to track and manage freight vehicles, heavy equipment, public transportation vehicles, as well as drivers with accuracy and efficiency. Will work with Vodacom, MTN, Telkom and Cell C networks.

Continuous and Reliable Operation
Uninterrupted real-time data on your vehicles' location and health are important for operation management and the safety of your drivers. The Vehicle Telematics 310 features low power consumption, ensuring a stable connection is maintained for constant tracking and monitoring even with insufficient power. Plus, with its Ni-MH 1200 mAh battery, the VT310 can continue working even when the machine is turned off. In the event cell service is unavailable, the device will continue to store location and diagnostic data until it's back online - you don’t have to worry about losing any information!

Featuring a rugged industrial design, the VT310 ensures stable operation in challenging vehicle environments. It can operate at voltages between 9-48V and withstand temperatures as low as -40°F and as high as 185°F. It’s also IP67 protected, meaning it’s water and dust-resistant.

Reliable Fleet Management
The VT310 has you covered for all your vehicle telematics needs. It integrates LTE, GNSS, geofencing, and inertial navigation, ensuring fleet managers can pinpoint where your vehicles are at all times. It can also track your vehicles' health, monitor driving habits, and control other aspects remotely, ensuring the safety of your drivers and cargo.

What's in the Kit

VT310 Device

Connectivity Cables

Benefits

Features and Benefits

Built-in GNSS module and real-time location tracking
Extensive interfaces, including serial ports, I/O, Bluetooth, 1- Wire
Multiple IoT Cloud Services Supported
Cache which over 30K location records, freeing you from concerns about data loss
IP67 protection rating

Wide voltage range of 9~48V covers all types of vehicle power supplies
built-in cellular and GPS antennas
Power Management Sleep mode
Driving behaviour and collision monitoring
Built-in FlexAPI, you can easily analyze protocols and acquire data

Specs

VT310 Specifications

INVEHICLE VT310 SPECIFICATIONS
ANTENNA
LTE Antenna	FPC built-in antenna
GNSS Antenna	Ceramic built-in antenna
Bluetooth Antenna	Ceramic built-in antenna
GNSS (GLOBAL NAVIGATION SATELLITE SYSTEM)
Satellite Support	GPS/GNSS/A-GNSS
Channe	31 channels
Sensitivity	-162 dBm, initial positioning time 32s
Collection Sensitivity	-156 dBm (hot start); -148 dBm (cold start)
Location Accuracy	2.5m (CEP50)
Update Frequency	1Hz by default, max. 10Hz
Low Power Consumption	Continuous operation: <15mA (@ 3.3V single system positioning)
INERTIAL SENSOR
Acceleration	Measurement range: ±2 / ±4 / ±8 / ±16g
Angular Velocity	Measurement range: ±125 / ±250 / ±500 / ±1000 / ±2000dps
ELECTRICAL FEATURES
Working Voltage	9-48V DC
Power Consumption	VT310-FS52: 0.55W VT310-FQ58: 0.77W
ELECTRICAL FEATURES
Capacity	1200mAh
Rated Voltage	3.7V
Cut-off Voltage	4.2V
Battery Materia	Lithium-ion battery
Working Temperature	Charging: 0 ~ 45 °C; Discharging: -20 ~ 60 ° C
Storage Temperature	For 1 month: -20 ~ 45 °C; For 6 months: -10 ~ 35 °C
ENVIRONMENT
Temperature	-20 ~ 60 °C (connected to main power) -20 ~ 60 °C (powered by internal battery) -10 ~ 35 °C (Long-term storage (≤ 6 months) with battery)
Humidity	95% RH @ 50 °C non-condensing
Shock and Vibration	US military standards 202G and 810F, SAE J1455
ESD	IEC 61000-4-2 (4KV test)
MECHANICAL FEATURES
Shell Material	Engineering plastic + engineering plastic alloy (PC + ABS)
Dimensions	Approximately 141 x 82 x 35 mm
Weight	152g
Protection Rating	IP67
VEHICLE FEATURES
CANBus	2 channels
J1708	1 channel
I/O
Ignition Signal	1 channel
Digital Input	4 channels
Digital Output	3-channels (max. 300 mA)
1-Wire	1 channel
Analog Input	1 channel
Serial Port	RS232
EXTERNAL INTERFACES
SIM Card Slot	2FF, push-in slot
I/O	26 PIN
LED Indicator	2 LED indicators: cellular status, GNSS status
SATELLITE NAVIGATION
GPS, GLONASS, Galileo, Beidou
